JAECOO 5 ELECTRIC ESTATE

Electric Vehicle Data

• Battery Capacity % guaranteed under warranty
  70
• Battery Capacity in kWh
  60.9
• Battery Charging Scenario 1 - Charge Time (Mins)
  27
• Battery Charging Scenario 1 - Percentage Change
  30-80
• Battery Charging Scenario 1 - Power Supply - kW
  80
• Battery Leased
  No
• Battery Type
  Lithium-ion
• Charging Port Location
  Right Side Rear
• Coupler/Connector Type
  CCS Type 2
• Maximum Charging Rate - kW
  80
• Standard manufacturers Battery warranty - Mileage
  100000
• Standard manufacturers Battery warranty - Years
  8
• Usable Battery Capacity
  Not Available
• WLTP - EC (kWh/100km) - Comb
  16.6
• WLTP - EC (miles/kWh) - Comb
  3.7
• WLTP - Pure Electric Range (km) - Comb
  400
• WLTP - Pure Electric Range (miles) - Comb
  248

Emissions - ICE

• CO
  Not Available
• CO2 (g/km)
  0
• HC
  Not Available
• HC+NOx
  Not Available
• Noise Level dB(A)
  Not Available
• NOx
  Not Available
• Particles
  Not Available
• Standard Emissions
  Not Available

Engine and Drive Train

• Camshaft
  Not Available
• Catalytic Convertor
  Not Available
• CC
  1
• Compression Ratio
  Not Available
• Cylinder Layout
  Not Available
• Cylinders
  Not Available
• Cylinders - Bore (mm)
  Not Available
• Cylinders - Stroke (mm)
  Not Available
• Engine Code
  Not Available
• Engine Layout
  Not Available
• Fuel Delivery
  Not Available
• Gears
  1 SPEED
• Number of Valves
  Not Available
• Transmission
  AUTO

Fuel Consumption - ICE

• EC Combined (mpg)
  Not Available
• EC Directive 1999/100/EC Applies
  Not Available
• EC Extra Urban (mpg)
  Not Available
• EC Urban (mpg)
  Not Available

General

• Alternative Fuel Qualifying
  Yes
• Badge Engine CC
  0.0
• Badge Power
  207
• Based On ID
  Not Available
• Coin Description
  61kWh
• Coin Series
  Pure
• Insurance Group 1 - 50 Effective January 07
  34U
• Did at least one aspect of this vehicle's safety give cause for concern?
  No
• Service Interval Frequency - Months
  12
• Service Interval Mileage
  10000
• Special Edition
  No
• Special Order
  No
• Standard manufacturers warranty - Mileage
  100000
• Standard manufacturers warranty - Years
  7
• Vehicle Homologation Class
  M1

Performance

• 0 to 62 mph (secs)
  7.7
• Engine Power - BHP
  207
• Engine Power - KW
  155
• Engine Torque - LBS.FT
  212
• Engine Torque - MKG
  29.4
• Engine Torque - NM
  288
• Top Speed
  108

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  N/A

Tyres

• Alloys?
  Yes
• Space Saver?
  No
• Tyre Size Front
  235/55 R18
• Tyre Size Rear
  235/55 R18
• Tyre Size Spare
  TYRE REPAIR KIT
• Wheel Style
  Not Available
• Wheel Type
  18" ALLOY

Vehicle Dimensions

• Height
  1650
• Height (including roof rails)
  Not Available
• Length
  4380
• Wheelbase
  2620
• Width
  1860

Weight and Capacities

• Fuel Tank Capacity (Litres)
  Not Available
• Minimum Kerbweight
  1690
• No. of Seats
  5
