LAND ROVER DISCOVERY SPORT SW SPECIAL EDITIONS

Electric Vehicle Data

• Battery Capacity % guaranteed under warranty
  72
• Battery Capacity in kWh
  12
• Battery Charging Scenario 1 - Charge Time (Mins)
  402
• Battery Charging Scenario 1 - Percentage Change
  0-100
• Battery Charging Scenario 1 - Power Supply - kW
  2.3
• Battery Charging Scenario 2 - Charge Time (Mins)
  132
• Battery Charging Scenario 2 - Percentage Change
  0-100
• Battery Charging Scenario 2 - Power Supply - kW
  7
• Battery Charging Scenario 3 - Charge Time (Mins)
  84
• Battery Charging Scenario 3 - Percentage Change
  0-80
• Battery Charging Scenario 3 - Power Supply - kW
  7
• Battery Charging Scenario 4 - Charge Time (Mins)
  30
• Battery Charging Scenario 4 - Percentage Change
  0-80
• Battery Charging Scenario 4 - Power Supply - kW
  32
• Battery Leased
  No
• Battery Type
  Lithium-ion
• Charging Port Location
  Left Side Rear
• Coupler/Connector Type
  Type 2
• Maximum Charging Rate - kW
  32
• Standard manufacturers Battery warranty - Mileage
  60000
• Standard manufacturers Battery warranty - Years
  6
• Usable Battery Capacity
  12
• WLTP - Equivalent AER (km) - Comb
  58
• WLTP - Equivalent AER (km) - Comb - TEH
  58
• WLTP - Equivalent AER (km) - Comb - TEL
  58
• WLTP - Equivalent AER (miles) - Comb
  36
• WLTP - Equivalent AER (miles) - Comb - TEH
  36
• WLTP - Equivalent AER (miles) - Comb - TEL
  36

Emissions - ICE

• HC+NOx
  Not Available
• Particles
  Not Available
• Standard Emissions
  EURO 6

Emissions - PHEV

• WLTP - CO2 Weighted (g/km) - Comb
  36
• WLTP - CO2 Weighted (g/km) - Comb - TEH
  36
• WLTP - CO2 Weighted (g/km) - Comb - TEL
  36

Engine and Drive Train

• Camshaft
  DOHC
• Catalytic Convertor
  Yes
• CC
  1498
• Compression Ratio
  10.5:1
• Cylinder Layout
  IN-LINE
• Cylinders
  3
• Cylinders - Bore (mm)
  83
• Cylinders - Stroke (mm)
  92.3
• Engine Layout
  FRONT TRANSVERSE
• Fuel Delivery
  TURBO DIRECT INJECTION
• Gears
  8 SPEED
• Number of Valves
  12
• Transmission
  AUTO

Fuel Consumption - ICE

• EC Directive 1999/100/EC Applies
  No

Fuel Consumption - PHEV

• WLTP - FC Weighted (l/100km) - Comb
  1.6
• WLTP - FC Weighted (l/100km) - Comb - TEH
  1.6
• WLTP - FC Weighted (l/100km) - Comb - TEL
  1.6
• WLTP - FC Weighted (mpg) - Comb
  174.3
• WLTP - FC Weighted (mpg) - Comb - TEH
  174.3
• WLTP - FC Weighted (mpg) - Comb - TEL
  174.3

General

• Alternative Fuel Qualifying
  Yes
• Badge Engine CC
  1.5
• Badge Power
  270
• Based On ID
  107882
• Coin Description
  P270e
• Coin Series
  Landmark Edn[5 Seat]
• Generation Mark
  2
• Insurance Group 1 - 50 Effective January 07
  39E
• Manufacturers Corrosion Perforation Guarantee - Years
  6
• Manufacturers Paintwork Guarantee - Years
  3
• Did at least one aspect of this vehicle's safety give cause for concern?
  No
• Special Edition
  Yes
• Special Order
  No
• Standard manufacturers warranty - Mileage
  Unlimited
• Standard manufacturers warranty - Years
  3
• Vehicle Homologation Class
  M1

Performance

• 0 to 62 mph (secs)
  7.4
• Engine Power - BHP
  269
• Engine Power - KW
  198
• Engine Power - RPM
  5000
• Engine Torque - LBS.FT
  398
• Engine Torque - MKG
  55.1
• Engine Torque - NM
  540
• Engine Torque - RPM
  2000
• Top Speed
  118

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  RDE 2

Tyres

• Alloys?
  Yes
• Space Saver?
  No
• Tyre Size Front
  235/55 R19
• Tyre Size Rear
  235/55 R19
• Tyre Size Spare
  Not Available
• Wheel Style
  STYLE 5136
• Wheel Type
  19" ALLOY

Vehicle Dimensions

• Height
  1727
• Height (including roof rails)
  Not Available
• Length
  4597
• Wheelbase
  2741
• Width
  2069
• Width (including mirrors)
  2173

Weight and Capacities

• Fuel Tank Capacity (Litres)
  58
• Gross Vehicle Weight
  2750
• Luggage Capacity (Seats Down)
  1574
• Luggage Capacity (Seats Up)
  780
• Max. Loading Weight
  657
• Max. Roof Load
  75
• Max. Towing Weight - Braked
  1600
• Max. Towing Weight - Unbraked
  750
• Minimum Kerbweight
  2093
• No. of Seats
  5
• Turning Circle - Kerb to Kerb
  11.8
